IN STOCK✈READY TO SHIP
Shipping with reliable carriers, professional handles, and trackable information.
Available shipping to other countries or regions, please fill in your address and refer to the checkout page information.
By LAN/Wi-Fi/Cloud to manage your messages
Display ability video, picture, text, clock, animation, etc.
Working voltage DC5V, input voltage 100-120V if the USA use
Made of waterproof cabinets, the front is the LED screen, this structure is easy to mount to your pillar or wall
Display Area size: Width 480cm x Height 240 cm (≈Width 16-FT x Height 8-FT)
External enclosure dimensions: Width 480cm x Height 240 cm (≈Width 16-FT x Height 8-FT)
Resolution: 1080p
Pitch: 10mm
Led Matrix: 480 x 240, 3-in-1 full-color display
Viewing angle: Horizontal 140° Vertical 140°
Operating Temp: -22 ~ 122F
Humidity range: 0-90% non-condensing
Waterproof: Yes
The screen is readable in direct sunlight.
The benefits you can get when you place an order:
* Shipping by express to doorstep delivery
* Shipment will come with some backup accessories
* We offer 1 year warranty period.
The giant outdoor LED screens are commonly used for displaying ads in public spaces such as shopping malls, airports, stadiums, and other high-traffic areas. Outdoor LED screens are popular because they provide a bright, high-contrast display that can be easily seen from a distance, making them an effective advertising tool.
Some of the advantages of using outdoor LED screens for ads include:
Attention-grabbing: LED screens are dynamic and eye-catching, making them an effective way to capture people's attention and get your message across.
High-impact: LED screens provide a high-resolution display with vivid colors, making your ad look more visually striking than traditional printed ads.
Versatile: LED screens can display a wide range of content, including static images, videos, and animations.
Cost-effective: it can be more cost-effective than traditional advertising, as you can change your ad content frequently and reach a larger audience.
Specifications of the LED video screen:
1. Pixel |
||||||
Pixel Pitch | 10mm | |||||
Pixel Configuration |
SMD3535 RGB 3in1 |
|||||
Environment | outdoor | |||||
Pixel Density | 10000 dots/m2 | |||||
Wavelength( nm) | Red: 625-630nm, Green: 525-530nm, Blue: 465-470nm | |||||
Luminous Intensity ( um) | Red: 300-500um, Green: 1300-1500um, Blue: 250-500nm | |||||
2. Module | ||||||
Module Resolution | 32*16 dots | |||||
Module Pixels | 512 dots | |||||
Module Size | 320*160 mm | |||||
Unit Panel Size(W*H*D) | customized | |||||
3. Screen parameters | ||||||
Viewing Distance | 10 - 100m | |||||
Color processing | Full Color | |||||
Brightness | ≥6000 CD/m2 | |||||
Brightness(Max./ Min.) | 1.2:1 | |||||
Colors | 16777216 colors | |||||
waterproof | IP65 | |||||
View Angle | Horizontal 140° Vertical 140° | |||||
LED Life Span | ≥100000 hours | |||||
Working Temperature | - 22ºF to + 122ºF | |||||
humidity-operating | 10%~95% | |||||
Operating System | WIN7/WIN8/WIN10, Android 4.3, and IOS 7.0 or above, web browser |
[What you’ll receive]:
Single-sided LED Display Screen size 480 x 240 cm
Power Cable
Communication wire
English Manual
Packing: Hard cardboard boxes + Wooden case
It's by FedEx-DHL- UPS the express shipping way delivery to you!
Estimated Delivery Time: 5-10 days (ships out within 18 business days)
According to your installation requirements, the structure of the cabinets may vary, we designed the LED screen's structure for you to easily mount it according to our communication.
We understand easy mounting is highly important, we design the structure of the LED sign according to the mounting way, which makes it easy to mount,
How can I get free shipping?
For small items such as some of led bulbs, led lights, we offer free shipping. If big items, free shipping is available if you order qualify quantity, please refer the checkout page.
When will my order be shipped?
Typically, within 1 ~3 business days can be shipped. Some customized items take a bit long within 5~7 business days can be shipped, for giant led screens, please refer to page notes.
Where will my order ship from?
Some small items available multiple warehouses in US, EU or UK linkage fulfilled your orders ensure delivery fast! If there is no stock or custom-made order, the item will be shipped from the leadleds CN warehouse. Once your order has shipped, you will receive a shipping confirmation via email with a tracking number.
Do you ship internationally?
Yes, we do. Insert your full address at checkout and shipping rates will be applied to your order, the total amount includes product and shipping.
The following countries or regions don't provide service.
Bhutan, Cook Islands, East Timor, French Polynesia, Kiribati, Marshall Islands, Palau, Papua New Guinea, Solomon Islands, Tonga, Tuvalu, Vanuatu, Wallis and Futuna Islands, as well as the Federated States of Micronesia (Kosre, Bonape, Yap, Truk).
How long will it take for my order to arrive?
We offer post delivery, express, air or by sea.
By post delivery time is within 1 to 2 weeks, many times even less. For remote places, the shipping time will be longer, you can track the shipment on the courier official site.
For giant led billboards, the default delivery is by express service 3~10 days delivery, the exact delivery date according to tracking information of express company.
If you like by sea to transportation, you can communicate with us before you place the order.
What shipping carriers do you use?
For smaller parcels we use postal service or express delivery depends on which shipping way you choose. For larger packages will ship by express or by sea.
The cooperative transportation companies are:
USPS, La Poste, Bpost, Singapore Post, Russian Post, etc
FedEx, DHL, UPS, TNT, SF express, etc
MSK, COSCO, EMC, APL, HMM, etc.
How can I track my order?
Once we fulfilled your order, you will receive an email notification with a tracking number. You will be able to track it immediately.
*Some LED signs are custom-made items, if we communicate by email, we'll produce and ship the items according to your confirmation.
